Hantek DPO7000 Series Digital Storage Oscilloscope | Observe the charging and discharging characteristics of capacitors |
|
|
Through an intuitive experiment, a oscilloscope was used to capture the complete process of capacitor charging and discharging in real time. |
|
|
Experiment configuration: |
| Electrolytic capacitor (470 μF) Dual resistance (1.5KΩ) Oscilloscope probe directly connected to capacitor Direct current regulated power supply |
|
|
Capacitor connected to the oscilloscope, powered by a 12V DC supply. |
Charging phase: Voltage starts fast and then rises slowly (waveform steeply → gradually → level) |
Discharge stage: Voltage starts fast and then slowly returns to zero (mirror descent curve) |
If we continuously charge and discharge, it can form a simple oscillation. In actual circuits, we can add transistors to control the charging and discharging of capacitors. |
